R1-TYPE HORIZONTAL WITH SINGLE HEAD TYPE


BIG SIZE HYDRAULIC RIVETING MACHINE
 This machine can directly rivet low carbon steel up to 30mm diameter and also can spread the tube's diameter up to 75mm to avoid the process of preheating.

　

Item  ST-120R1
Riveting Capacity Solid Rivet 5-20ψ
Max.Stroke 35 m/m
Max.H.Die-head to bed 220 m/m
Spindle Revolution 1720 RPM
Max.depth 220 m/m
Drive Motor 2/2 HP
pressure used (kg/cm2) 20-70 kg
Adjusting work time 1-6 Sec
Net Weight 1500 kg
Height of Machine m/m 1300
Width m/m 800
Length m/m 1700
